Spiral Mixer Removable Bowl


Spiral Mixer Removable Bowl

150 kg flour / 250 kg dough

Spiral mixer suitable for all kinds of  bread production methods by means of its divider shear profiled in relation with the geometry of the spiral providing limited oxygenation of the dough which gives bread more flavour.


Structure in epoxy powdered
Dividing blade, spiral arm, bowl and safety grid in stainless steel
Movement transmission by pulleys and belts
Safety device stops automatically the machine when the grid is lifted
Motors are protected from overcharging and short circuit
Reverse bowl rotation at first speed
Mixing time setting for 1st and 2nd speed
Electronic control with high resistant membrane on keyboard
Hydraulic lifting system with self tipping suitable for both side tipping
Control system is of the hold-to-run type
Low tension 24 Volt


Spiral Mixer

Standard Construction

Motorised stainless steel bowl

24 V control circuit

2 speeds

2 Timers

Structure in epoxy powdered
ABS safety lid

Stainless steel spiral arms and divider shear

150 kg flour / 250 kg dough

Spiral Mixer


KMKspmM 250 Kg dough


FMKSPM 250 Kg dough


PLC digital control

Stainless Steel Body

 380 V 50 Hz - 3 phase

Electricity Connection
